| Part Number | M236HVR01.0 CELL |
| Mark | AUO |
| Gréisst | 23.6 |
| Applikatioun | Desktop Monitor Gami |
| Opléisung | 1920×1080 |
| Zesummesetzung | a-Si TFT-LCD , CELL |
| Hellegkeet | |
| CR | 3000:1 |
| Faarwen | 16.7M |
| Géigeliicht | No |
| Interface | |
| Panel Mark | AUO |
| Panel Gréisst | 23.6" |
| Resolutioun | 1920(RGB)×1080, FHD, 93PPI |
| Affichage Beräich | 521.395(W)×293.285(H) mm |
| Kontur Gréisst | 532.995(W)×305.185(H) ×1.11(D) mm |
| Hellegkeet | 0 cd/m² |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| Glas Déift | 0.40+0.40 mm |
| weisen Faarwen | 16.7M 69% NTSC |
| Frequenz | 165Hz |
| Gewiicht | 530g (Typ.) |
| Panel Modell | M236HVR01.0 CELL |
| Panel Typ | a-Si TFT-LCD , CELL |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | Antiglare (Haze 40%), Hard coating (3H) |
| Kontrast Verhältnis | 3000:1 (Typ.) (TM) |
| Display Modus | VA, Normally Black, Transmissive |
| Äntwert Zäit | 20 (Typ.)(G to G) |
| transmissivitéit | 3.22% (Typ.)(with Polarizer) |
| Lampe Typ | No B/L |
| Touchscreens | Without |
| Applikatioun | Desktop Monitor Gaming |
