| Part Number | HR236WU1-300 |
| Mark | BOE |
| Gréisst | 23.6 |
| Applikatioun | DMPC |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 250 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | BOE |
| Panel Modell | HR236WU1-300 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 23.6 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | ADS, Normally Black, Transmissive |
| aktiv Beräich | 521.28×293.22 mm |
| skizzéieren | 544.8×320.5×10.5 mm |
| Uewerfläch | Antiglare (Haze 25%), Hard coating (3H) |
| Hellegkeet | 250 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC), sRGB |
| Äntwert Zäit | 14 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 4 stringsWLEDWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | DMPC |
| LM170E01-TLBF | LG Display | 17.0 | 1280×1024 |
| LM201W01-STB1 | LG Display | 20.1 | 1680×1050 |
| LM230WF5-TLF1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLH1 | LG Display | 23.0 | 1920×1080 |
| LTM230HT02 | Samsung | 23.0 | 1920×1080 |
| M185BGE-L10 | Innolux | 18.5 | 1366×768 |
| M190EN03 V2 | AUO | 19.0 | 1280×1024 |
| M215HW02 V0 | AUO | 21.5 | 1920×1080 |
| M236H1-L01 | Innolux | 23.6 | 1920×1080 |
| P236MWF1 R0 | IVO | 23.6 | 1920×1080 |
