| Part Number | M236HJJ-P02 Rev.C4 |
| Mark | Innolux |
| Gréisst | 23.6 |
| Applikatioun | Desktop Monitor |
| Opléisung | 1920×1080 |
| Zesummesetzung | a-Si TFT-LCD, CELL |
| Hellegkeet | |
| CR | 3000:1 |
| Faarwen | 16.7M |
| Géigeliicht | No |
| Interface | |
| Mark | Innolux |
| Modell | M236HJJ-P02 Rev.C4 |
| diagonal Gréisst | 23.6 inch |
| Typ | a-Si TFT-LCD, CELL |
| Pixel Format | 1920(RGB)×1080 [FHD] 93PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 521.28(H)×293.22(V) mm |
| kontur dim. | 534.28(H)×306.252(V) mm |
| bezel Beräich | - |
| Behandlung | Antiglare (Haze 25%), Hard coating (3H) |
| luminance | 0 cd/m² |
| Kontrast Verhältnis | 3000:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 20/5 (Typ.)(Tr/Td) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Betribssystemer Modus | Super MVA, Normally Black, Transmissive |
| Plackedicke | - |
| Iwwerdroung | 4.8% (Typ.)(with Polarizer) |
| Ënnerstëtzung Faarf | 16.7M 72% NTSC |
| Liichtquell | No B/L |
| Gewiicht | TBD |
| entworf fir | Desktop Monitor |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
