| Part Number | LTI220MT02 |
| Mark | Samsung |
| Gréisst | 22.0 |
| Applikatioun | PID |
| Opléisung | 1680×1050 |
| Zesummesetzung | LCM |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 16.7M |
| Géigeliicht | No B/L |
| Interface | HDMI |
| Panel Mark | SAMSUNG |
| Panel Modell | LTI220MT02 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 22.0 inch |
| Resolutioun | 1680(RGB)×1050 , WSXGA+ |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 473.76×296.1 mm |
| skizzéieren | 493.7×371×22 mm |
| Uewerfläch | Clear, Hard coating (2H) |
| Hellegkeet | |
| Kontrast Verhältnis | 500:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE19315% |
| Äntwert Zäit | 45/5 (Typ.)(Tr/Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | No B/L |
| Signal Interface | HDMI, 49 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | PID |
| LM220WE1-TLK1 | LG Display | 22.0 | 1680×1050 |
| LM220WE1-TLM1 | LG Display | 22.0 | 1680×1050 |
| LTI220MT02 | Samsung | 22.0 | 1680×1050 |
| LTM220M1-L01 | Samsung | 22.0 | 1680×1050 |
| LTM220MT09 | Samsung | 22.0 | 1680×1050 |
| LTM220MT12 | Samsung | 22.0 | 1680×1050 |
| M220EW01 V0 | AUO | 22.0 | 1680×1050 |
| M220Z1-L01 | Innolux | 22.0 | 1680×1050 |
| M220Z1-L03 | Innolux | 22.0 | 1680×1050 |
| M220Z1-L05 | Innolux | 22.0 | 1680×1050 |
| LD420WUN-SCA1 | LG Display | 42 | 1920×1080 |
| LD420WXN-SAA1 | LG Display | 42 | 1366×768 |
| LD470EUD-SDA1 | LG Display | 47 | 1920×1080 |
| LTI430LA02 | Samsung | 43 | 1920×480 |
| LTI460HM02 | Samsung | 46 | 1920×1080 |
| LTI460HM03 | Samsung | 46 | 1920×1080 |
| ND168TXP01 | 16.8 | 1366×378 | |
| P320HVN01.1 | AUO | 31.5 | 1920×1080 |
| P420HW02 V0 | AUO | 42 | 1920×1080 |
| RX366HDL-C07 | ROGIN | 36.6 | 1920×290 |
