| Part Number | ND168TXP01 |
| Mark | |
| Gréisst | 16.8 |
| Applikatioun | PID |
| Opléisung | 1366×378 |
| Zesummesetzung | LCM |
| Hellegkeet | 800 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | |
| Panel Modell | ND168TXP01 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 16.8 inch(1/2 cut of 18.5") |
| Resolutioun | 1366(RGB)×378 |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 409.8×113.4 mm |
| skizzéieren | 430.37×137.3×11.5 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 800 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC), CIE193171% |
| Äntwert Zäit | 5 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 8-bit), 30 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | PID |
