| Part Number | LTA149B780F |
| Mark | TOSHIBA |
| Gréisst | 14.9 |
| Applikatioun | IA |
| Opléisung | 1280×390 |
| Zesummesetzung | LCM |
| Hellegkeet | 400 |
| CR | 500:1 |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | Toshiba Matsushita |
| Panel Modell | LTA149B780F |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 14.9 inch |
| Resolutioun | 1280(RGB)×390 |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 360.94×109.98 mm |
| skizzéieren | 407.5×136×20.5 mm |
| Uewerfläch | Glare (Haze 0%) |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 10/20 (Typ.)(Tr/Td) |
| Vue Wénkel | 80/80/45/75 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 2 pcsCCFLWithout Driver |
| Signal Interface | LVDS (1 ch, 6-bit), 20 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | IA |
