| Part Number | LS038Y7DX01 |
| Mark | SHARP |
| Gréisst | 3.8 |
| Applikatioun | MPH |
| Opléisung | 480×800 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 500:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | SHARP |
| Panel Modell | LS038Y7DX01 |
| Panel Typ | CG-Silicon , LCM |
| Panel Gréisst | 3.8 inch |
| Resolutioun | 480(RGB)×800 , WVGA |
| Display Modus | Normally Black, Transflective |
| aktiv Beräich | 49.68×82.8 mm |
| skizzéieren | 54.6×93 mm |
| Uewerfläch | |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.)(Transmissive)12:1 (Typ.)(Reflective) |
| weisen Faarwen | 262K (6-bit), CIE193170% |
| Äntwert Zäit | 40/40 (Typ.)(Tr/Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 7S1PWLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit) + SPI, 50 pins |
| Input Volt | 3.85/1.8V (Typ.)(VDC/VDDIO) |
| rohs: | |
| Applikatioun | MPH |
