| Part Number | LH450WX1-SD01 |
| Mark | LG Display |
| Gréisst | 4.5 |
| Applikatioun | MPH |
| Opléisung | 720×1280 |
| Zesummesetzung | LCM |
| Hellegkeet | 500 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Panel Mark | LG Display |
| Panel Modell | LH450WX1-SD01 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 4.5 inch |
| Resolutioun | 720(RGB)×1280 , WXGA |
| Display Modus | AH3-IPS, Normally Black, Transmissive |
| aktiv Beräich | 55.512×98.688 mm |
| skizzéieren | 59.61×108.47 mm |
| Uewerfläch | Antireflection |
| Hellegkeet | 500 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193170% |
| Äntwert Zäit | 17/18 (Typ.)(Tr/Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 9S1PWLEDWithout Driver |
| Signal Interface | MIPI (4 data lanes), 30 pins |
| Input Volt | 1.8/3.0/3.0V (Typ.)(IOVCC/VCI/VCC) |
| Applikatioun | MPH |
| ACX399CMP-7 | SONY | 2.9 | 640×360 |
| AMS320FH01-0 | Samsung | 3.2 | 240×400 |
| AMS369FG03-002 | Samsung | 3.7 | 480×800 |
| AMS427GL45-0 | Samsung | 4.3 | 480×800 |
| DX08D11VM0AAA | KOE | 3.0 | 480×800 |
| GCX141AKM-E | SONY | 3.2 | 240×400 |
| H598QAN01.0 | AUO | 6.0 | 1440×2560 |
| LH220Q32-FD01 | LG Display | 2.2 | 320×320 |
| LS026Q7UX01 | SHARP | 2.6 | 320×240 |
| TX10D121VM0AAA | JDI | 4.0 | 480×800 |
