| Part Number | LQ050A5AG03 |
| Mark | Sharp |
| Gréisst | 5.0 |
| Applikatioun | Automotive Display |
| Opléisung | 320×234 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 60:1 |
| Faarwen | Full |
| Géigeliicht | 1 pcs CCFL , 10K hours , No Driver |
| Interface | Analog |
| Fabrikant beschwéiert | Sharp |
| Modell Numm | LQ050A5AG03 |
| Écran Gréisst | 5.0 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 320(RGB)×234 79PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 102.124 × 74.763 (H×V) |
| Kontur (mm) | 126.8 × 89.9 × 16.5 (H×V×D) |
| Bezel Beräich (mm) | - |
| Behandlung | Antireflection |
| luminance | 320 cd/m² (Typ.) |
| Kontrast Verhältnis | 60 : 1 (Typ.) (TM) |
| Vue Wénkel | 65/65/40/65 (Typ.)(CR≥5) |
| Äntwert | 30/50 (Typ.)(Tr/Td) ms |
| gutt Vue op | - |
| Aarbecht Modus | TN, Normally White, Transmissive |
| Faarfdéift | Full color |
| mass | 180g (Max.) |
| benotzt fir | Automotive Display |
| Erfrëschungsrate | - |
| touchscreen | Without |
| Signal Typ | Analog RGB , Connector 22 pins |
| Spannungsversuergung | 8.0/-5.0V (Typ.)(VSH/VSL) |
| max. Bewäertungen | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
