| Part Number | LP140WH2-TLN1 |
| Mark | LG Display |
| Gréisst | 14.0 |
| Applikatioun | NBPC |
| Opléisung | 1366×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 200 |
| CR | 500:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | LG Display |
| Panel Modell | LP140WH2-TLN1 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 14.0 inch |
| Resolutioun | 1366(RGB)×768 , WXGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 309.399×173.952 mm |
| skizzéieren | 322.3×204.6×3.6 mm |
| Form Stil | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| Uewerfläch | Glare (Haze 0%), Hard coating (3H) |
| Hellegkeet | 200 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193145% |
| Äntwert Zäit | 16 (Typ.)(Tr+Td) |
| Vue Wénkel | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 10S4PWLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 6-bit), 40 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
| LP140WD2-TLE2 | LG Display | 14.0 | 1600×900 |
| LP140WF1-SPU1 | LG Display | 14.0 | 1920×1080 |
| LP140WH1-TPD1 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLA1 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLE2 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLE3 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLF1 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLT1 | LG Display | 14.0 | 1366×768 |
| LP140WHU-TPB2 | LG Display | 14.0 | 1366×768 |
| LP140WX1-TL02 | LG Display | 14.0 | 1280×768 |
| B125HAN02.0 | AUO | 12.5 | 1920×1080 |
| B154SW02 V0 | AUO | 15.4 | 1680×1050 |
| LP154WU1-TLA2 | LG Display | 15.4 | 1920×1200 |
| LP156WH2-TLR1 | LG Display | 15.6 | 1366×768 |
| LP173WF3-SLB2 | LG Display | 17.3 | 1920×1080 |
| LT121SU-125 | Samsung | 12.1 | 800×600 |
| LTN140AT11-L02 | Samsung | 14.0 | 1366×768 |
| LTN173HT02-T01 | Samsung | 17.3 | 1920×1080 |
| N141I3-L05 | Innolux | 14.1 | 1280×800 |
| N156HGE-EA1 | Innolux | 15.6 | 1920×1080 |
