LG Display LP140WH2-TLF3 Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


LP140WH2-TLF3

LP140WH2-TLF3
LP140WH2-TLF3
LP140WH2-TLF3 thumb LP140WH2-TLF3 thumb
Mark
LG Display
Gréisst
14.0
Applikatioun
NBPC
Opléisung
1366×768
Zesummesetzung
LCM
Hellegkeet
200
CR
350:1
Faarwen
262K
Backlight
WLED
Interface
LVDS
In Stock
560
Spezifikatioune

Part Number LP140WH2-TLF3
MarkLG Display
Gréisst14.0
ApplikatiounNBPC
Opléisung1366×768
ZesummesetzungLCM
Hellegkeet200
CR350:1
Faarwen262K
GéigeliichtWLED
InterfaceLVDS
Panel MarkLG Display
Panel ModellLP140WH2-TLF3
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst14.0 inch
Resolutioun1366(RGB)×768 , WXGA
Display ModusTN, Normally White, Transmissive
aktiv Beräich309.399×173.952 mm
skizzéieren320.4×204.6 mm
Form StilFlat (PCBA Flat, Depth 3.4~4.0mm)
Uewerfläch
Hellegkeet200 cd/m² (Typ.)
Kontrast Verhältnis350:1 (Typ.)
weisen Faarwen262K (6-bit)
Äntwert Zäit16 (Typ.)(Tr+Td)
Vue Wénkel45/45/15/35 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe TypWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (1 ch, 6-bit), 40 pins
Input Volt3.3V (Typ.)
ApplikatiounNBPC
Famill Modell
LP140WD2-TLD2 LG Display 14.0 1600×900
LP140WH1-TLA2 LG Display 14.0 1366×768
LP140WH1-TLC3 LG Display 14.0 1366×768
LP140WH1-TLD6 LG Display 14.0 1366×768
LP140WH1-TPD1 LG Display 14.0 1366×768
LP140WH2-TLA2 LG Display 14.0 1366×768
LP140WH2-TLT1 LG Display 14.0 1366×768
LP140WH4-TLN1 LG Display 14.0 1366×768
LP140WH8-TLA1 LG Display 14.0 1366×768
LP140WH8-TPH1 LG Display 14.0 1366×768
