LP140WF5-SPB2

LP140WF5-SPB2
LP140WF5-SPB2
LP140WF5-SPB2 thumb LP140WF5-SPB2 thumb
Mark
LG Display
Gréisst
14.0
Applikatioun
NBPC
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
CR
700:1
Faarwen
262K
Backlight
WLED
Interface
eDP
In Stock
4328
Spezifikatioune

Part Number LP140WF5-SPB2
MarkLG Display
Gréisst14.0
ApplikatiounNBPC
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet
CR700:1
Faarwen262K
GéigeliichtWLED
InterfaceeDP
Panel MarkLG Display
Panel ModellLP140WF5-SPB2
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst14.0 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusAH-IPS, Normally Black, Transmissive
aktiv Beräich309.31×173.99 mm
Uewerfläch
Hellegkeet
Kontrast Verhältnis700:1 (Typ.)
weisen Faarwen262K (6-bit)
Äntwert Zäit25 (Typ.)(Tr+Td)
Vue Wénkel80/80/80/80 (Min.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe TypWLEDEmbedded (LED Driver)
Signal InterfaceeDP (2 Lanes), 30 pins
Input Volt3.3V (Typ.)
ApplikatiounNBPC
