LC470EUD-SDM1

LC470EUD-SDM1
LC470EUD-SDM1
LC470EUD-SDM1 thumb LC470EUD-SDM1 thumb
Mark
LG Display
Gréisst
47
Applikatioun
LCTV
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
450
CR
1600:1
Faarwen
16.7M/1.06B
Backlight
WLED
Interface
LVDS
In Stock
16753
Spezifikatioune

Part Number LC470EUD-SDM1
MarkLG Display
Gréisst47
ApplikatiounLCTV
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet450
CR1600:1
Faarwen16.7M/1.06B
GéigeliichtWLED
InterfaceLVDS
Panel MarkLG Display
Panel ModellLC470EUD-SDM1
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst47 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusIPS, Normally Black, Transmissive
aktiv Beräich1039.68×584.82 mm
skizzéieren1078×626 mm
UewerflächAntiglare (Haze 2%), Hard coating (3H)
Hellegkeet450 cd/m² (Typ.)
Kontrast Verhältnis1600:1 (Typ.)
weisen Faarwen16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172%
Äntwert Zäit6 (Typ.)(G to G)
Vue Wénkel89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
Frequenz120Hz
Lampe TypWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (4 ch, 8/10-bit), 92 pins
Input Volt12.0V (Typ.)
ApplikatiounLCTV
