LC470EUD-SDF1

LC470EUD-SDF1
LC470EUD-SDF1
LC470EUD-SDF1 thumb LC470EUD-SDF1 thumb
Mark
LG Display
Gréisst
47
Applikatioun
LCTV
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
400
CR
1600:1
Faarwen
16.7M/1.06B
Backlight
WLED
Interface
LVDS
In Stock
40
Spezifikatioune

Part Number LC470EUD-SDF1
MarkLG Display
Gréisst47
ApplikatiounLCTV
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet400
CR1600:1
Faarwen16.7M/1.06B
GéigeliichtWLED
InterfaceLVDS
Panel MarkLG Display
Panel ModellLC470EUD-SDF1
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst47 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusS-IPS, Normally Black, Transmissive
aktiv Beräich1039.68×584.82 mm
skizzéieren1078.6×626 mm
UewerflächAntiglare (Haze 10%), Hard coating (2H)
Hellegkeet400 cd/m² (Typ.)
Kontrast Verhältnis1600:1 (Typ.)
weisen Faarwen16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172%
Äntwert Zäit5 (Typ.)(G to G), 6 (Typ.)(MPRT)
Vue Wénkel89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
Frequenz120Hz+120Hz
Lampe TypWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (4 ch, 8/10-bit), 92 pins
Input Volt12.0V (Typ.)
ApplikatiounLCTV
Famill Modell
LC470EUD-SDF2 LG Display 47 1920×1080
LC470EUE-SEM1 LG Display 47 1920×1080
LC470EUF-SDF1 LG Display 47 1920×1080
LC470EUH-PEF1 LG Display 47 1920×1080
LC470EUH-SCA1 LG Display 47 1920×1080
LC470EUN-FFM1 LG Display 47 1920×1080
LC470EUN-PEF1 LG Display 47 1920×1080
LC470EUN-SDF1 LG Display 47 1920×1080
LC470EUN-SEF1 LG Display 47 1920×1080
LC470EUN-SEM2 LG Display 47 1920×1080
