| Part Number | LC470DUE-FGA3 |
| Mark | LG Display |
| Gréisst | 47 |
| Applikatioun | LCTV |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 1200:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | LG Display |
| Panel Modell | LC470DUE-FGA3 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 47 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | IPS, Normally Black, Transmissive |
| aktiv Beräich | 1039.68×584.82 mm |
| skizzéieren | 1071.01×621.61 mm |
| Uewerfläch | Antiglare (Haze 1%), Hard coating (3H) |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 1200:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193168% |
| Äntwert Zäit | 9 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 51 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | LCTV |
| LC320EUD-SDF3 | LG Display | 31.5 | 1920×1080 |
| LC320WXN-SAC2 | LG Display | 31.5 | 1366×768 |
| LC420DUE-SFR2 | LG Display | 42 | 1920×1080 |
| LC420DUK-SGP1 | LG Display | 42 | 1920×1080 |
| LC420EUJ-SFK2 | LG Display | 42 | 1920×1080 |
| LC470DUT-SEF2 | LG Display | 47 | 1920×1080 |
| LC490DUY-SHA1 | LG Display | 49 | 1920×1080 |
| LTY400HA01 | Samsung | 40 | 1920×1080 |
| T460HVN02.2 | AUO | 46 | 1920×1080 |
| T500HVN05.0 CELL | AUO | 50 | 1920×1080 |
