LC470DUT-SEF2

LC470DUT-SEF2
LC470DUT-SEF2
LC470DUT-SEF2 thumb LC470DUT-SEF2 thumb
Mark
LG Display
Gréisst
47
Applikatioun
LCTV
Opléisung
1920×1080
Zesummesetzung
CELL
Hellegkeet
0
CR
1300:1
Faarwen
16.7M
Backlight
No B/L
Interface
Mini LVDS
In Stock
13065
Spezifikatioune

Part Number LC470DUT-SEF2
MarkLG Display
Gréisst47
ApplikatiounLCTV
Opléisung1920×1080
ZesummesetzungCELL
Hellegkeet0
CR1300:1
Faarwen16.7M
GéigeliichtNo B/L
InterfaceMini LVDS
Panel MarkLG Display
Panel ModellLC470DUT-SEF2
Panel Typ a-Si TFT-LCD , CELL
Panel Gréisst47 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusIPS, Normally Black, Transmissive
aktiv Beräich1039.68×584.82 mm
skizzéieren1046.68×594.02 mm
UewerflächHard coating (2H), Reflection 2.0% (Max.)
Glas Déift0.50+0.50 mm
transmissivitéit4.5% (Typ.)(with Polarizer)
Kontrast Verhältnis1300:1 (Typ.)
weisen Faarwen16.7M (8-bit)
Äntwert Zäit4/4 (Typ.)(Tr/Td)
Vue Wénkel89/89/89/89 (MIn.)(CR≥10)(L/R/U/D)
Frequenz240Hz
Signal InterfaceMini LVDS, 160 pins
Input Volt12.0V (Typ.)(VLCD)
ApplikatiounLCTV
