LC320EXN-SDA3

LC320EXN-SDA3
LC320EXN-SDA3
LC320EXN-SDA3 thumb LC320EXN-SDA3 thumb
Mark
LG Display
Gréisst
31.5
Applikatioun
LCTV
Opléisung
1366×768
Zesummesetzung
LCM
Hellegkeet
380
CR
1200:1
Faarwen
16.7M
Backlight
WLED
Interface
LVDS
In Stock
4636
Spezifikatioune

Part Number LC320EXN-SDA3
MarkLG Display
Gréisst31.5
ApplikatiounLCTV
Opléisung1366×768
ZesummesetzungLCM
Hellegkeet380
CR1200:1
Faarwen16.7M
GéigeliichtWLED
InterfaceLVDS
Panel MarkLG Display
Panel ModellLC320EXN-SDA3
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst31.5 inch
Resolutioun1366×768(RGB) , WXGA
Display ModusS-IPS, Normally Black, Transmissive
aktiv Beräich697.685×392.256 mm
skizzéieren735.4×433×31.7 mm
UewerflächAntiglare (Haze 10%), Hard coating (3H)
Hellegkeet380 cd/m² (Typ.)
Kontrast Verhältnis1200:1 (Typ.)
weisen Faarwen16.7M (8-bit)
Äntwert Zäit9 (Typ.)(G to G)
Vue Wénkel89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe TypWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (1 ch, 8-bit), 30 pins
Input Volt12.0V (Typ.)
ApplikatiounLCTV
Famill Modell
LC320EUA-PEF1 LG Display 31.5 1920×1080
LC320EUA-PFF1 LG Display 31.5 1920×1080
LC320EUD-SDA2 LG Display 31.5 1920×1080
LC320EUF-FEP1 LG Display 31.5 1920×1080
LC320EUH-SCA1 LG Display 31.5 1920×1080
LC320EUN-SDV1 LG Display 31.5 1920×1080
LC320EUN-SEF2 LG Display 31.5 1920×1080
LC320EXE-SDA1 LG Display 31.5 1366×768
LC320EXJ-SEE2 LG Display 31.5 1366×768
LC320EXN-FEP1 LG Display 31.5 1366×768
