| Part Number | HV320WXC-100 |
| Mark | BOE |
| Gréisst | 31.5 |
| Applikatioun | LCTV |
| Opléisung | 1366×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 450 |
| CR | 1200:1 |
| Faarwen | 16.7M |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | BOE |
| Panel Modell | HV320WXC-100 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 31.5 inch |
| Resolutioun | 1366(RGB)×768 , WXGA |
| Display Modus | ADS, Normally Black, Transmissive |
| aktiv Beräich | 697.685×392.256 mm |
| skizzéieren | 760×450 mm |
| Uewerfläch | Antiglare (Haze 10%), Hard coating (3H) |
| Hellegkeet | 450 cd/m² (Typ.) |
| Kontrast Verhältnis | 1200:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193172% |
| Äntwert Zäit | 8 (Max.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 4 pcsCCFLEmbedded (Inverter) |
| Signal Interface | LVDS (1 ch, 8-bit), 30 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | LCTV |
| HV320WHB-N00 | BOE | 31.5 | 1366×768 |
| HV320WHB-N06 | BOE | 31.5 | 1366×768 |
| HV320WHB-N80 | BOE | 31.5 | 1366×768 |
| HV320WX2-200 | BOE | 31.5 | 1366×768 |
| HV320WX2-201 | BOE | 31.5 | 1366×768 |
| HV320WX2-206 | BOE | 31.5 | 1366×768 |
| HV320WX2-500 | BOE | 31.5 | 1366×768 |
| HV320WXC-100 | BOE | 31.5 | 1366×768 |
| HV320WXC-201 | BOE | 31.5 | 1366×768 |
| LC320WXE-SCA1 | LG Display | 31.5 | 1366×768 |
| HV320WXC-201 | BOE | 31.5 | 1366×768 |
| LC370WUB-SCB1 | LG Display | 37 | 1920×1080 |
| LC470EUD-SDM1 | LG Display | 47 | 1920×1080 |
| LC470EUD-SEF2 | LG Display | 47 | 1920×1080 |
| LC550DUY-SHA1 | LG Display | 55 | 1920×1080 |
| LC650EQF-FHM2 | LG Display | 65 | 3840×2160 |
| LC650EQF-PHF1 | LG Display | 65 | 3840×2160 |
| LTA400HM02 | Samsung | 40 | 1920×1080 |
| LTA460HQ23 | Samsung | 46 | 1920×1080 |
| LTA550HJ19 | Samsung | 55 | 1920×1080 |
