| Part Number | HT260WXC-100 |
| Mark | BOE |
| Gréisst | 26.0 |
| Applikatioun | LCTV |
| Opléisung | 1366×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 400 |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | BOE |
| Panel Modell | HT260WXC-100 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 26.0 inch |
| Resolutioun | 1366(RGB)×768 , WXGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 575.769×323.712 mm |
| skizzéieren | 626×373 mm |
| Uewerfläch | Antiglare (Haze 25%), Hard coating (3H) |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Äntwert Zäit | 5 (Typ.)(G to G) |
| Vue Wénkel | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 4 pcsCCFLWithout Driver |
| Signal Interface | LVDS (1 ch, 8-bit), 30 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | LCTV |
| LC215EXE-SGA1 | LG Display | 21.5 | 1366×768 |
| LC320EUD-SDF2 | LG Display | 31.5 | 1920×1080 |
| LC420WX8-SLA1 | LG Display | 42 | 1366×768 |
| T216XW01 V0 | AUO | 21.6 | 1366×768 |
| T315XW03 VE | AUO | 31.5 | 1366×768 |
| T460HW08 V0 | AUO | 46 | 1920×1080 |
| V236H1-L01 | Innolux | 23.6 | 1920×1080 |
| V260H1-LE2 | Innolux | 26.0 | 1920×1080 |
| V500HJ1-LE2 | Innolux | 50 | 1920×1080 |
| V546H1-LH2 | Innolux | 55 | 1920×1080 |
