| Part Number | V546H1-LH2 |
| Mark | Innolux |
| Gréisst | 55 |
| Applikatioun | LCTV |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 500 |
| CR | 4000:1 |
| Faarwen | 16.7M/1.07B |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | CMO |
| Panel Modell | V546H1-LH2 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 55 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | Super MVA, Normally Black, Transmissive |
| aktiv Beräich | 1209.6×680.4 mm |
| skizzéieren | 1267.6×738.4×41.5 mm |
| Uewerfläch | Antiglare (Haze 11%), Hard coating (3H) |
| Hellegkeet | 500 cd/m² (Typ.) |
| Kontrast Verhältnis | 4000:1 (Typ.) |
| weisen Faarwen | 16.7M/1.07B (8-bit / 8-bit + Hi-FRC), CIE193172% |
| Äntwert Zäit | 4.5 (Typ.)(G to G) |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| Frequenz | 120Hz (60Hz Input) |
| Lampe Typ | 22 pcsCCFLEmbedded (Inverter) |
| Signal Interface | LVDS (2 ch, 10-bit), 51 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | LCTV |
| LC550EUD-FFF1 | LG Display | 55 | 1920×1080 |
| LC550EUE-SEU1 | LG Display | 55 | 1920×1080 |
| LTI550HN14 | Samsung | 55 | 1920×1080 |
| P550HVN06.0 | AUO | 55 | 1920×1080 |
| ST5461D01-1 | CSOT | 55 | 3840×2160 |
| T546HW01 V0 | AUO | 55 | 1920×1080 |
| V546H1-LH2 | Innolux | 55 | 1920×1080 |
| V546H1-LS1 | Innolux | 55 | 1920×1080 |
| V546H1-LS2 | Innolux | 55 | 1920×1080 |
| V546HK3-LS5 Rev.C7 | Innolux | 55 | 1920×1080 |
| LC320WXE-SBV2 | LG Display | 31.5 | 1366×768 |
| LC420DUE-FGA6 | LG Display | 42 | 1920×1080 |
| LTA320AP16 | Samsung | 31.5 | 1366×768 |
| LTA320HM01 | Samsung | 31.5 | 1920×1080 |
| ST3151A04-7 | CSOT | 31.5 | 1366×768 |
| T216XW01 V0 | AUO | 21.6 | 1366×768 |
| T315HW07 V2 | AUO | 31.5 | 1920×1080 |
| T315XW03 VD | AUO | 31.5 | 1366×768 |
| V370B1-L01 | Innolux | 37 | 1366×768 |
| V500DK1-KS2 Rev.HA | Innolux | 50 | 3840×2160 |
