| Part Number | HSD156JUW2-A13 |
| Mark | HannStar |
| Gréisst | 15.6 |
| Applikatioun | Outdoor High Brightn |
| Opléisung | 1920×1080 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | 4 |
| Interface | LVDS |
| Panel Mark | HannStar |
| Panel Gréisst | 15.6" |
| Resolutioun | 1920(RGB)×1080, FHD, 141PPI |
| Affichage Beräich | 344.16(W)×193.59(H) mm |
| Kontur Gréisst | 363.7(W)×215.7(H) mm |
| Hellegkeet | 850 cd/m² (Typ.) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 70% |
| Frequenz | 60Hz |
| Panel Gewiicht | TBD |
| Signal Interface | LVDS (2 ch, 8-bit) , 50 pins Connector |
| Input Volt | 5.0V (Typ.) |
| Ëmwelt | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| Panel Modell | HSD156JUW2-A13 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | Hard coating |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Display Modus | IPS Pro, Normally Black, Transmissive |
| Äntwert Zäit | 15/15 (Max.)(Tr+Td) |
| Lampe Typ | 4 strings WLED , 30K hours , Without Driver |
| Touchscreens | Without |
| Applikatioun | Outdoor High Brightness Automotive Display |
