| Part Number | B156XW04 V5 |
| Mark | AUO |
| Gréisst | 15.6 |
| Applikatioun | NBPC |
| Opléisung | 1366×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 200 |
| CR | 500:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Modell | B156XW04 V5 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 15.6 inch |
| Resolutioun | 1366(RGB)×768 , WXGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 344.232×193.536 mm |
| skizzéieren | 359.5×223.8×3.8 mm |
| Form Stil | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| Uewerfläch | Glare (Haze 0%), Hard coating (3H) |
| Hellegkeet | 200 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193145% |
| Äntwert Zäit | 2/6 (Typ.)(Tr/Td) |
| Vue Wénkel | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 6-bit), 40 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
| B156XTK01.0 | AUO | 15.6 | 1366×768 |
| B156XTN02.4 | AUO | 15.6 | 1366×768 |
| B156XTN03.1 | AUO | 15.6 | 1366×768 |
| B156XTN04.5 | AUO | 15.6 | 1366×768 |
| B156XTN05.0 | AUO | 15.6 | 1366×768 |
| B156XTT01.1 | AUO | 15.6 | 1366×768 |
| B156XW01 V1 | AUO | 15.6 | 1366×768 |
| B156XW01 V2 | AUO | 15.6 | 1366×768 |
| B156XW03 V0 | AUO | 15.6 | 1366×768 |
| B156XW04 V5 | AUO | 15.6 | 1366×768 |
| B133EW01 V3 | AUO | 13.3 | 1280×800 |
| LP133X7-P2IB | LG Display | 13.3 | 1024×768 |
| LP140WH2-TLEA | LG Display | 14.0 | 1366×768 |
| LTD121EDDX | TOSHIBA | 12.1 | 1024×768 |
| LTD141EN9B | TOSHIBA | 14.1 | 1400×1050 |
| LTM12C505K | TOSHIBA | 12.1 | 1024×768 |
| LTN141AT03-301 | Samsung | 14.1 | 1280×800 |
| N141X6-L01 | Innolux | 14.1 | 1024×768 |
| N156BGE-E21 | Innolux | 15.6 | 1366×768 |
| N156O6-L04 | Innolux | 15.6 | 1600×900 |
