| Part Number | HSD104KXN1-A20 |
| Mark | HannStar |
| Gréisst | 10.4 |
| Applikatioun | Automotive Display |
| Opléisung | 1024×768 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 900:1 |
| Faarwen | 262K/16.2M |
| Géigeliicht | WLED |
| Interface | |
| Fabrikant beschwéiert | HannStar |
| Modell Numm | HSD104KXN1-A20 |
| Écran Gréisst | 10.4 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 1024(RGB)×768 (XGA) 123PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 211.2 × 158.4 (H×V) |
| Kontur (mm) | - |
| luminance | - |
| Kontrast Verhältnis | 900 : 1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Äntwert | - |
| gutt Vue op | Symmetry |
| Aarbecht Modus | IPS Pro, Normally Black, Transmissive |
| Faarfdéift | 262K/16.2M |
| mass | - |
| benotzt fir | Automotive Display |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
