| Part Number | HSD061IDW1-A00-R00 |
| Mark | HannStar |
| Gréisst | 6.1 |
| Applikatioun | Automotive Display |
| Opléisung | 800×480 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 262K |
| Géigeliicht | 6S2P |
| Interface | Parallel |
| Panel Mark | HannStar |
| Panel Modell | HSD061IDW1-A00-R00 |
| Panel Gréisst | 6.1" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 800(RGB)×480, WVGA, 153PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 132(W)×79.2(H) mm |
| bezel Ouverture | 143.3(W)×81.6(H) mm |
| Kontur Gréisst | 144.8(W)×87.6(H) ×4.8(D) mm |
| Uewerfläch | Antiglare (Haze 8%), Hard coating (3H) |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) (TM) |
| Vue Wénkel | 75/75/60/70 (Typ.)(CR≥10) |
| Display Modus | TN, Normally White, Transmissive |
| beschte Vue op | - |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| weisen Faarwen | 262K 48% NTSC |
| Lampe Typ | 6S2P WLED , 10K hours , Without Driver |
| Frequenz | 60Hz |
| Touchscreens | 4-wire Resistive Touch |
| Panel Gewiicht | 140g (Max.) |
| Applikatioun | Automotive Display |
| Signal Interface | Parallel RGB (1 ch, 6-bit) + SPI , 50 pins FPC |
| Input Volt | 1.8/3.3/3.3V (Typ.)(VDD1/VDD2/VCI) |
| Ëmwelt | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -40 ~ 85 °C |
| A061FW01 V0 | AUO | 6.1 | 480×234 |
| A061VW01 V0 | AUO | 6.1 | 800×480 |
| CLAA061LA0ACW | CPT | 6.1 | 800×480 |
| CLAA061LA0BCW | CPT | 6.1 | 800×480 |
| CLAA061LA0DCW | CPT | 6.1 | 800×480 |
| GCX142AKM-E | SONY | 6.1 | 800×480 |
| K6488L-FF | CITIZEN | 6.1 | 640×480 |
| LA061WQ1-TD04 | LG Display | 6.1 | 480×272 |
| LQ061Y1VG01 | SHARP | 6.1 | 800×480 |
| PM061WX1 | E Ink | 6.1 | 800×480 |
