| Part Number | H220VA01 |
| Mark | AUO |
| Gréisst | 2.2 |
| Applikatioun | Mobile Phone |
| Opléisung | 240×320 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 75:19:1 |
| Faarwen | 262K |
| Géigeliicht | 4S1P WLED , No Driver |
| Interface | Parallel |
| Fabrikant beschwéiert | AUO |
| Écran Gréisst | 2.2 inch |
| Pixel Zuel | 240(RGB)×320 (QVGA) 180PPI |
| aktiv Beräich (mm) | 33.84 × 45.12 (H×V) |
| Bezel Beräich (mm) | 35.4 × 46.92 (H×V) |
| luminance | 100 cd/m² (Typ.) |
| Vue Wénkel | 47/28/30/80 (Typ.)(CR≥10) |
| gutt Vue op | 6 o'clock |
| Faarfdéift | 262K 42% NTSC |
| mass | - |
| Erfrëschungsrate | - |
| Signal Typ | Parallel RGB (1 ch, 6-bit) + SPI , 39 pins FPC |
| Spannungsversuergung | 2.8V (Typ.) |
| max. Bewäertungen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| Modell Numm | H220VA01 |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 40.6 × 56.66 × 3.11 (H×V×D) |
| Behandlung | - |
| Kontrast Verhältnis | 75 : 1 (Typ.) (TM) 9:1 (Typ.) (RF) |
| Äntwert | 29 (Typ.)(Tr+Td) ms |
| Aarbecht Modus | TN, Normally White, Transflective |
| benotzt fir | Mobile Phone |
| touchscreen | Without |
