| Part Number | G270QAN01.0 |
| Mark | AUO |
| Gréisst | 27.0 |
| Applikatioun | Industrial |
| Opléisung | 2560×1440 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | 4 |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Gréisst | 27.0" |
| Resolutioun | 2560(RGB)×1440, Quad-HD, 108PPI |
| Affichage Beräich | 596.74(W)×335.66(H) mm |
| Kontur Gréisst | 630(W)×368.2(H) ×15.6(D) mm |
| Hellegkeet | 350 cd/m² (Typ.) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 100% Adobe RGB |
| Frequenz | 60Hz |
| Panel Gewiicht | 3.15Kgs (Typ.) |
| Signal Interface | LVDS (4 ch, 8-bit) , 92 pins Connector |
| Input Volt | 5.0V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Modell | G270QAN01.0 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | 601.6(W)×340.15(H) mm |
| Uewerfläch | Antiglare |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Display Modus | AHVA, Normally Black, Transmissive |
| Äntwert Zäit | 8/8 (Typ.)(Tr/Td) |
| Lampe Typ | 4 strings WLED , 30K hours , Without Driver |
| Touchscreens | Without |
| Applikatioun | Industrial |
| LM270WF5-SLM1 | LG Display | 27.0 | 1920×1080 |
| LM270WF6-SSZ1 | LG Display | 27.0 | 1920×1080 |
| LM270WF7-SSB1 | LG Display | 27.0 | 1920×1080 |
| LM270WQ1-SDA2 | LG Display | 27.0 | 2560×1440 |
| LM270WQ3-SLB2 | LG Display | 27.0 | 2560×1440 |
| M270DAN01.0 | AUO | 27.0 | 2560×1440 |
| M270DTN01.0 | AUO | 27.0 | 2560×1440 |
| M270DTN01.3 | AUO | 27.0 | 2560×1440 |
| M270HGE-L20 | Innolux | 27.0 | 1920×1080 |
| P270MWN1 R0 | IVO | 27.0 | 1920×1080 |
