| Part Number | M270DTN01.0 |
| Mark | AUO |
| Gréisst | 27.0 |
| Applikatioun | DMPC |
| Opléisung | 2560×1440 |
| Zesummesetzung | LCM |
| Hellegkeet | 350 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Modell | M270DTN01.0 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 27.0 inch |
| Resolutioun | 2560(RGB)×1440 , Quad-HD |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 596.736×335.664 mm |
| skizzéieren | 613.6×356.85×10.9 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193172% |
| Äntwert Zäit | 3.5/1.5 (Typ.)(Tr/Td) |
| Vue Wénkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 144Hz |
| Lampe Typ | 18S4PWLEDWithout Driver |
| Signal Interface | LVDS (8 ch, 8-bit), 130 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | DMPC |
