| Part Number | G270HAN01.2 |
| Mark | AUO |
| Gréisst | 27.0 |
| Applikatioun | Industrial |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | 22S4P WLED , 50K hours , No Driver |
| Interface | LVDS |
| Fabrikant beschwéiert | AUO |
| Modell Numm | G270HAN01.2 |
| Écran Gréisst | 27.0 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 1920(RGB)×1080 (FHD) 81PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 597.888 × 336.312 (H×V) |
| Kontur (mm) | 611.48 × 355.81 × 13.3 (H×V×D) |
| Bezel Beräich (mm) | 601.49 × 339.91 (H×V) |
| Behandlung | Antiglare |
| luminance | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000 : 1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Äntwert | 14 (Typ.)(Tr+Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | AHVA, Normally Black, Transmissive |
| Faarfdéift | 16.7M 72% NTSC |
| mass | 2.87Kgs (Typ.) |
| benotzt fir | Industrial |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Signal Typ | LVDS (2 ch, 8-bit) , Connector 30 pins |
| Spannungsversuergung | 5.0V (Typ.) |
| max. Bewäertungen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
