| Part Number | G104XVN01.1 |
| Mark | AUO |
| Gréisst | 10.4 |
| Applikatioun | Industrial |
| Opléisung | 1024×768 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 3000:1 |
| Faarwen | 262K/16.2M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Modell | G104XVN01.1 |
| Panel Gréisst | 10.4" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 1024(RGB)×768, XGA, 123PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 210.4(W)×157.8(H) mm |
| bezel Ouverture | 215.4(W)×161.8(H) mm |
| Kontur Gréisst | 238.6(W)×175.8(H) ×7(D) mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | - |
| Kontrast Verhältnis | 3000:1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Display Modus | AMVA3, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 20/10 (Typ.)(Tr/Td) |
| weisen Faarwen | 262K/16.2M |
| Lampe Typ | WLED , With LED Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | - |
| Applikatioun | Industrial |
| Signal Interface | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| Input Volt | 3.3V (Typ.) |
