| Part Number | G101STN01.D |
| Mark | AUO |
| Gréisst | 10.1 |
| Applikatioun | Industrial |
| Opléisung | 1024×600 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | WLED , 50K hours , With LED Driver |
| Interface | LVDS |
| Fabrikant beschwéiert | AUO |
| Écran Gréisst | 10.1 inch |
| Pixel Zuel | 1024(RGB)×600 (WSVGA) 117PPI |
| aktiv Beräich (mm) | 222.72 × 125.28 (H×V) |
| Bezel Beräich (mm) | 226.43 × 128.1 (H×V) |
| luminance | 450 cd/m² (Typ.) |
| Vue Wénkel | 70/70/60/60 (Typ.)(CR≥10) |
| gutt Vue op | - |
| Faarfdéift | 262K/16.7M 45% NTSC |
| mass | 180g (Typ.) |
| Erfrëschungsrate | 60Hz |
| Signal Typ | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| Spannungsversuergung | 3.3V (Typ.) |
| max. Bewäertungen | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
| Modell Numm | G101STN01.D |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 235 × 143 × 5.2 (H×V×D) |
| Behandlung | Antiglare, Hard coating (3H) |
| Kontrast Verhältnis | 500 : 1 (Typ.) (TM) |
| Äntwert | 7/9 (Typ.)(Tr/Td) ms |
| Aarbecht Modus | TN, Normally White, Transmissive |
| benotzt fir | Industrial |
| touchscreen | Without |
