| Part Number | G057QN01 V2 |
| Mark | AUO |
| Gréisst | 5.7 |
| Applikatioun | IA |
| Opléisung | 320×240 |
| Zesummesetzung | LCM |
| Hellegkeet | 800 |
| CR | 800:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | AUO |
| Panel Modell | G057QN01 V2 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 5.7 inch |
| Resolutioun | 320(RGB)×240 , QVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 115.2×86.4 mm |
| skizzéieren | 144×104.6×12.8 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 800 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193150% |
| Äntwert Zäit | 15/10 (Typ.)(Tr/Td) |
| Vue Wénkel | 80/80/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDEmbedded (LED Driver) |
| Signal Interface | CMOS (1 ch, 6-bit), 33 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | IA |
