| Part Number | CLAA061LA0NCW |
| Mark | CPT |
| Gréisst | 6.1 |
| Applikatioun | Automotive Display |
| Opléisung | 800×480 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 400:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | TTL |
| Mark | CPT |
| diagonal Gréisst | 6.1 inch |
| Pixel Format | 800(RGB)×480 [WVGA] 153PPI |
| aktiv Beräich | 136.2(H)×72(V) mm |
| luminance | - |
| Vue Richtung | 6 o'clock |
| Vue Wénkel | 70/70/50/70 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 262K 70% NTSC |
| Gewiicht | - |
| Frame Taux | 60Hz |
| Interface Typ | TTL (1 ch, 6-bit) |
| Ëmwelt | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| Modell | CLAA061LA0NCW |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | - |
| Kontrast Verhältnis | 400:1 (Typ.) (TM) |
| Äntwert Zäit | 20 (Typ.)(Tr+Td) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Liichtquell | WLED , 30K hours |
| entworf fir | Automotive Display |
| Touch Panel | Without |
| CLAA061LA0ACW | CPT | 6.1 | 800×480 |
| CLAA061LA0BCW | CPT | 6.1 | 800×480 |
| CLAA062LA01CW | CPT | 6.2 | 800×480 |
| CLAA069JA11CW | CPT | 7.0 | 480×234 |
| CLAA069LA0NCW | CPT | 7.0 | 800×480 |
| CLAA069LA1AAW | CPT | 7.0 | 800×480 |
| CLAA069LB02CW | CPT | 7.0 | 800×480 |
| CLAA069LB03CW | CPT | 7.0 | 800×480 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| CLAA069LC01XW | CPT | 7.0 | 800×480 |
