| Part Number | CC580PV5D |
| Mark | PANDA |
| Gréisst | 58 |
| Applikatioun | TV Sets |
| Opléisung | 3840×2160 |
| Zesummesetzung | Oxide TFT-LCD , CELL |
| Hellegkeet | |
| CR | 6000:1 |
| Faarwen | 1.07B |
| Géigeliicht | No |
| Interface | |
| Mark | PANDA |
| diagonal Gréisst | 58 inch |
| Pixel Format | 3840(RGB)×2160 [UHD] 76PPI |
| aktiv Beräich | 1270.08(H)×721.44(V) mm |
| bezel Beräich | - |
| luminance | 0 cd/m² |
| Vue Richtung | Symmetry |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Plackedicke | 0.50+0.50 mm |
| Ënnerstëtzung Faarf | 1.07B 70% NTSC |
| Gewiicht | 2.84Kgs (Typ.) |
| Frame Taux | 60Hz |
| Modell | CC580PV5D |
| Typ | Oxide TFT-LCD , CELL |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 1282.88(H)×734.44(V) ×1.36(D) mm |
| Behandlung | Antiglare, Hard coating (2H) |
| Kontrast Verhältnis | 6000:1 (Typ.) (TM) |
| Äntwert Zäit | 8 (Typ.)(G to G) |
| Betribssystemer Modus | UV2A, Normally Black, Transmissive |
| Iwwerdroung | 5.5% (Typ.)(with Polarizer) |
| Liichtquell | No B/L |
| entworf fir | TV Sets |
| Touch Panel | Without |
| LK580Z3LA13 | SHARP | 58 | 2560×1080 |
| V580DJ2-QS5 | Innolux | 58 | 3840×2160 |
| V580DK1-QS2 | Innolux | 58 | 3840×2160 |
| V580DK2-KS1 | Innolux | 58 | 3840×2160 |
| V580DK2-KS1 Rev.C8 | Innolux | 58 | 3840×2160 |
| V580HJ1-LD6 | Innolux | 58 | 1920×1080 |
| V580HJ1-LE6 | Innolux | 58 | 1920×1080 |
| V580HK1-LD6 | Innolux | 58 | 1920×1080 |
| V580HK1-LE6 | Innolux | 58 | 1920×1080 |
| V580HK1-LS6 | Innolux | 58 | 1920×1080 |
