| Part Number | V580HJ1-LD6 |
| Mark | Innolux |
| Gréisst | 58 |
| Applikatioun | LCTV |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 350 |
| CR | 4000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | INNOLUX |
| Panel Modell | V580HJ1-LD6 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 58 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | Super MVA, Normally Black, Transmissive |
| aktiv Beräich | 1270.08×721.44 mm |
| skizzéieren | 1290.3×744.7×63.6 mm |
| Uewerfläch | Antiglare (Haze 1%) |
| Hellegkeet | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 4000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193172% |
| Äntwert Zäit | 9.5 (Typ.)(G to G) |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 51 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | LCTV |
| LC320DXJ-SFK1 | LG Display | 31.5 | 1366×768 |
| LC320EUN-SEM2 | LG Display | 31.5 | 1920×1080 |
| LC420EUN-SFF3 | LG Display | 42 | 1920×1080 |
| LTA400HT-L07 | Samsung | 40 | 1920×1080 |
| LTA520HB13 | Samsung | 52 | 1920×1080 |
| T260XW05 V0 | AUO | 26.0 | 1366×768 |
| T320HVN01.0 | AUO | 31.5 | 1920×1080 |
| T460HVN08.2 CELL | AUO | 46 | 1920×1080 |
| V150V1-T02 | Innolux | 15.0 | 640×480 |
| V580DK1-LS1 | Innolux | 58 | 3840×2160 |
