| Part Number | C080VTN04.0 |
| Mark | AUO |
| Gréisst | 8.0 |
| Applikatioun | Automotive Display |
| Opléisung | 800×480 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | Parallel |
| Mark | AUO |
| Modell | C080VTN04.0 |
| diagonal Gréisst | 8.0 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 800(RGB)×480 [WVGA] 115PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 175.2(H)×105.12(V) mm |
| kontur dim. | - |
| bezel Beräich | - |
| Behandlung | Antiglare |
| Vue Richtung | - |
| Äntwert Zäit | 15/20 (Typ.)(Tr/Td) |
| Vue Wénkel | 60/60/40/60 (Typ.)(CR≥10) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Ënnerstëtzung Faarf | 262K |
| Liichtquell | WLED |
| Gewiicht | - |
| entworf fir | Automotive Display |
| Frame Taux | 60Hz |
| Touch Panel | - |
| Interface Typ | Parallel RGB (1 ch, 6-bit) , 60 pins Connector |
| Ëmwelt | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -40 ~ 95 °C |
