| Part Number | BV045FHM-L00-1S00 |
| Mark | BOE |
| Gréisst | 4.5 |
| Applikatioun | Mobile Phone |
| Opléisung | 1080×1620 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | |
| Mark | BOE |
| Modell | BV045FHM-L00-1S00 |
| diagonal Gréisst | 4.5 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1080(RGB)×1620 434PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 63.115(H)×94.673(V) mm |
| kontur dim. | 68.14(H)×104.97(V) ×3(D) mm |
| bezel Beräich | - |
| Behandlung | Anti Fingerprint |
| luminance | 580 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 50 (Max.)(G to G) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| Betribssystemer Modus | ADS, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 100% sRGB |
| Liichtquell | WLED [8S2P] , 15K hours , W/O Driver |
| Gewiicht | TBD |
| entworf fir | Mobile Phone |
| Frame Taux | 60Hz |
| Touch Panel | In-Cell Touch |
| Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
