| Part Number | B080EAK02.2 |
| Mark | AUO |
| Gréisst | 8.0 |
| Applikatioun | Pad & Tablet |
| Opléisung | 800×1280 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 900:1 |
| Faarwen | 16.7M |
| Géigeliicht | 4S5P |
| Interface | MIPI |
| Panel Mark | AUO |
| Panel Modell | B080EAK02.2 |
| Panel Gréisst | 8.0" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 800(RGB)×1280, WXGA, 188PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 107.64(W)×172.224(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 113.72(W)×183.764(H) ×4.1(D) mm |
| Uewerfläch | Glare (Haze 0%) |
| Hellegkeet | 360 cd/m² (Typ.) |
| Kontrast Verhältnis | 900:1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Display Modus | AHVA, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 25 (Typ.)(Tr+Tf) |
| weisen Faarwen | 16.7M 58% NTSC |
| Lampe Typ | 4S5P WLED , 15K hours , Without Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | 120g (Max.) |
| Applikatioun | Pad & Tablet |
| Signal Interface | MIPI (4 data lanes) , 39 pins Connector |
| Input Volt | 1.8/3.3V (Typ.)(VCC1/VC2) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| AT080TN03 V.1 | Innolux | 8.0 | 800×480 |
| AT080TN52 V.1 | Innolux | 8.0 | 800×600 |
| B080EAN01.1 | AUO | 8.0 | 800×1280 |
| B080EAN02.0 | AUO | 8.0 | 800×1280 |
| B080EAN02.2 | AUO | 8.0 | 800×1280 |
| C080VW04 V0 | AUO | 8.0 | 800×480 |
| CLAA080MB0DCW | CPT | 8.0 | 800×600 |
| LD080WX2-SMN1 | LG Display | 8.0 | 800×1280 |
| LT080EE04000 | TOSHIBA | 8.0 | 1600×768 |
| TM080TDHG01 | Tianma | 8.0 | 1024×768 |
