| Part Number | AT056TN03 |
| Mark | Innolux |
| Gréisst | 5.6 |
| Applikatioun | VDP |
| Opléisung | 320×234 |
| Zesummesetzung | LCM |
| Hellegkeet | 350 |
| CR | 300:1 |
| Faarwen | |
| Géigeliicht | CCFL |
| Interface | Analog |
| Panel Mark | INNOLUX |
| Panel Modell | AT056TN03 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 5.6 inch |
| Resolutioun | 320(RGB)×234 |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 113.28×84.708 mm |
| skizzéieren | 126.5×100 mm |
| Uewerfläch | |
| Hellegkeet | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 300:1 (Typ.) |
| weisen Faarwen | |
| Äntwert Zäit | 15/20 (Typ.)(Tr/Td) |
| Vue Wénkel | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| Lampe Typ | 1 pcsCCFLWithout Driver |
| Signal Interface | TFT Specific Analog RGB, 26 pins |
| Input Volt | 5/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| rohs: | |
| Applikatioun | VDP |
| AT050TN22 V.1 | Innolux | 5.0 | 640×480 |
| AT050TN23 V.1 | Innolux | 5.0 | 640×480 |
| AT050TN33 | Innolux | 5.0 | 480×272 |
| AT050TN33 V.1 | Innolux | 5.0 | 480×272 |
| AT050TN34 | Innolux | 5.0 | 480×272 |
| AT050TN35 | Innolux | 5.0 | 480×272 |
| AT056TN52 | Innolux | 5.6 | 640×480 |
| AT056TN52 V.2 | Innolux | 5.6 | 640×480 |
| AT056TN52 V.4 | Innolux | 5.6 | 640×480 |
| AT056TN53 V.1 | Innolux | 5.6 | 640×480 |
| A040CN01 V2 | AUO | 4.0 | 480×234 |
| A070FW03 V3 | AUO | 7.0 | 480×234 |
| A070FW03 V4 | AUO | 7.0 | 480×234 |
| AT050TN22 V.1 | Innolux | 5.0 | 640×480 |
| DLC0500AIG-2 | Other | 5.0 | 640×480 |
| LQ070T3AG02 | SHARP | 7.0 | 480×234 |
| LR700BA9005 | Innolux | 7.0 | 480×234 |
| PA050XSH | E Ink | 5.0 | 320×234 |
| PA064DS1 | E Ink | 6.4 | 320×234 |
| TM056KDH01 | Tianma | 5.6 | 320×234 |
