| Part Number | AT043TN14 V.1 |
| Mark | Innolux |
| Gréisst | 4.3 |
| Applikatioun | Portable Navigation |
| Opléisung | 480×272 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | Parallel |
| Mark | Innolux |
| Modell | AT043TN14 V.1 |
| diagonal Gréisst | 4.3 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 480(RGB)×272 [WQVGA] 128PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 95.04(H)×53.856(V) mm |
| kontur dim. | - |
| bezel Beräich | - |
| Behandlung | Antiglare |
| luminance | - |
| Kontrast Verhältnis | 500:1 (Typ.) (TM) |
| Vue Richtung | 6 o'clock |
| Äntwert Zäit | 10/15 (Typ.)(Tr/Td) |
| Vue Wénkel | 70/70/50/70 (Typ.)(CR≥10) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Ënnerstëtzung Faarf | 16.7M |
| Liichtquell | WLED |
| Gewiicht | - |
| entworf fir | Portable Navigation MP3 PMP |
| Frame Taux | - |
| Touch Panel | 4-wire Resistive Touch |
| Interface Typ | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| Stroumversuergung | (2.5/3.3)/5.0V (Typ.)(VDD/AVDD) |
| Ëmwelt | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| 43WQW4T | SII | 4.3 | 480×272 |
| AT043TN13 | Innolux | 4.3 | 480×272 |
| AT043TN13 TP | Innolux | 4.3 | 480×272 |
| AT043TN24 V.1 | Innolux | 4.3 | 480×272 |
| AT043TN24 V.7 | Innolux | 4.3 | 480×272 |
| AT043TN25 V.1 | Innolux | 4.3 | 480×272 |
| AT043TN25 V.2 | Innolux | 4.3 | 480×272 |
| ET043001DM6 | EDT | 4.3 | 480×272 |
| LB043WQ3-TD03 | LG Display | 4.3 | 480×272 |
| LR043AC212 | Innolux | 4.3 | 480×272 |
