| Part Number | LR043AC212 |
| Mark | Innolux |
| Gréisst | 4.3 |
| Applikatioun | PND |
| Opléisung | 480×272 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 400:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | Parallel/Serial |
| Panel Mark | ChiHsin |
| Panel Modell | LR043AC212 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 4.3 inch |
| Resolutioun | 480(RGB)×272 , WQVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 95.04×53.856 mm |
| skizzéieren | 105.5×67.2 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 400:1 (Typ.) |
| weisen Faarwen | 16.7M |
| Äntwert Zäit | 15/35 (Typ.)(Tr/Td) |
| Vue Wénkel | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| Lampe Typ | 7S1PWLEDWithout Driver |
| Signal Interface | Digital RGB (8/24-bit), 60 pins |
| Input Volt | 3/5.0V (Typ.)(DVDD/AVDD) |
| rohs: | |
| Applikatioun | PND |
| AM480272H3TMQW-TW2H | AMPIRE | 4.3 | 480×272 |
| AMS429QC08 | Samsung | 4.3 | 540×960 |
| DLC0430EZG-11 | Other | 4.3 | 480×272 |
| DLC0430LZG-T | Other | 4.3 | 480×272 |
| H430VL02 V4 | AUO | 4.3 | 480×800 |
| HSD043I9W1-A00 | HannStar | 4.3 | 480×272 |
| LQ043Y1DX01B | SHARP | 4.3 | 480×800 |
| LR043AC212 | Innolux | 4.3 | 480×272 |
| LR043JC111 | Innolux | 4.3 | 480×272 |
| LR043JC211 | Innolux | 4.3 | 480×272 |
| 43WQW4T | SII | 4.3 | 480×272 |
| A050FW02 V5 | AUO | 5.0 | 480×272 |
| CLAA048LA0BCW | CPT | 4.8 | 800×480 |
| LMS500HF05 | Samsung | 5.0 | 480×272 |
| LMS500HF13-003 | Samsung | 5.0 | 480×272 |
| LQ036T1DG01 | SHARP | 3.6 | 272×480 |
| LQ043T1DH42 | SHARP | 4.3 | 480×272 |
| LQ043T3DX0G | SHARP | 4.3 | 480×272 |
| TM047NBH01 | Tianma | 4.7 | 480×272 |
| TM050NDH01 | Tianma | 5.0 | 480×272 |
