| Part Number | AM-800480N3TZQW-57H |
| Mark | AMPIRE |
| Gréisst | 5.0 |
| Applikatioun | Industrial Automotiv |
| Opléisung | 800×480 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 262K |
| Géigeliicht | 3S6P WLED , 50K hours , With LED Driver |
| Interface | |
| Fabrikant beschwéiert | AMPIRE |
| Modell Numm | AM-800480N3TZQW-57H |
| Écran Gréisst | 5.0 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 800(RGB)×480 (WVGA) 188PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 108 × 64.8 (H×V) |
| Kontur (mm) | 119.7 × 78.3 × 10.05 (H×V×D) |
| Bezel Beräich (mm) | 109.6 × 66.4 (H×V) |
| Behandlung | - |
| luminance | 1000 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000 : 1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Äntwert | 30 (Typ.)(Tr+Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | IPS, Normally Black, Transmissive |
| Faarfdéift | 262K |
| mass | - |
| benotzt fir | Industrial Automotive Display |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
