| Part Number | AM-800480AZTMQW-50H |
| Mark | AMPIRE |
| Gréisst | 5.0 |
| Applikatioun | Industrial |
| Opléisung | 800×480 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 600:1 |
| Faarwen | 16.7M |
| Géigeliicht | 3S6P |
| Interface | |
| Panel Mark | AMPIRE |
| Panel Gréisst | 5.0" |
| Resolutioun | 800(RGB)×480, WVGA, 188PPI |
| Affichage Beräich | 108(W)×64.8(H) mm |
| Kontur Gréisst | 119.7(W)×78(H) ×6.1(D) mm |
| Hellegkeet | 1000 cd/m² (Typ.) |
| Vue Wénkel | 75/75/70/60 (Typ.)(CR≥10) |
| beschte Vue op | - |
| weisen Faarwen | 16.7M 47% NTSC |
| Frequenz | 60Hz |
| Gewiicht | - |
| Panel Modell | AM-800480AZTMQW-50H |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | Antiglare |
| Kontrast Verhältnis | 600:1 (Typ.) (TM) |
| Display Modus | TN, Normally White, Transmissive |
| Äntwert Zäit | 2/6 (Typ.)(Tr/Td) |
| Lampe Typ | 3S6P WLED , 50K hours , Without Driver |
| Touchscreens | Without |
| Applikatioun | Industrial |
