| Part Number | AM-19201200B1TZQW-00-B |
| Mark | AMPIRE |
| Gréisst | 10.1 |
| Applikatioun | Industrial Outdoor H |
| Opléisung | 1920×1200 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | AMPIRE |
| diagonal Gréisst | 10.1 inch |
| Pixel Format | 1920(RGB)×1200 [WUXGA] 224PPI |
| aktiv Beräich | 216.806(H)×135.504(V) mm |
| bezel Beräich | - |
| luminance | 1000 cd/m² (Typ.) |
| Vue Richtung | Symmetry |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 16.7M 53% NTSC |
| Gewiicht | - |
| Frame Taux | 60Hz |
| Interface Typ | LVDS (2 ch, 8-bit) , 40 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -30 ~ 80 °C |
| Modell | AM-19201200B1TZQW-00-B |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 243.45(H)×155.2(V) ×9.61(D) mm |
| Behandlung | Antiglare |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Betribssystemer Modus | Normally Black, Transmissive |
| Liichtquell | WLED , 50K hours , With LED Driver |
| entworf fir | Industrial Outdoor High Brightness |
| Touch Panel | Without |
| AM-19201200B1TZQW-T00 | AMPIRE | 10.1 | 1920×1200 |
| B101EAN01.2 | AUO | 10.1 | 1280×800 |
| B101EAN02.2 | AUO | 10.1 | 800×1280 |
| B101UAN01.9 | AUO | 10.1 | 1920×1200 |
| HSD100IFW4-A00 | HannStar | 10.1 | 1024×600 |
| HSD101PWW1-B00 | HannStar | 10.1 | 1280×800 |
| LP101WH4-SLP2 | LG Display | 10.1 | 1366×768 |
| LTN101NT02-W05 | Samsung | 10.1 | 1024×600 |
| N101ICE-G63 | Innolux | 10.1 | 1280×800 |
| VVX10F011B00 | Panasonic | 10.1 | 1920×1200 |
