| Part Number | AM-1024600K7TMQW-T54H |
| Mark | AMPIRE |
| Gréisst | 7.0 |
| Applikatioun | Industrial |
| Opléisung | 1024×600 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 700:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | 8S3P WLED , 50K hours , With LED Driver |
| Interface | |
| Fabrikant beschwéiert | AMPIRE |
| Modell Numm | AM-1024600K7TMQW-T54H |
| Écran Gréisst | 7.0 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 1024(RGB)×600 (WSVGA) 169PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 153.6 × 90 (H×V) |
| Kontur (mm) | 165.5 × 104.44 × 10.77 (H×V×D) |
| luminance | 850 cd/m² (Typ.) |
| Kontrast Verhältnis | 700 : 1 (Typ.) (TM) |
| Vue Wénkel | 75/75/70/75 (Typ.)(CR≥10) |
| Äntwert | 20/20 (Typ.)(Tr/Td) ms |
| gutt Vue op | 6 o'clock |
| Aarbecht Modus | TN, Normally White, Transmissive |
| Faarfdéift | 262K/16.7M |
| mass | TBD |
| benotzt fir | Industrial |
| Erfrëschungsrate | 60Hz |
| touchscreen | PCAP |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
