| Part Number | AC070MR11 |
| Mark | Mitsubishi |
| Gréisst | 7.0 |
| Applikatioun | Industrial Outdoor H |
| Opléisung | 800×480 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | 2 |
| Interface | LVDS |
| Panel Mark | Mitsubishi |
| Panel Gréisst | 7.0" |
| Resolutioun | 800(RGB)×480, WVGA, 133PPI |
| Affichage Beräich | 152.4(W)×91.44(H) mm |
| Kontur Gréisst | 169.8(W)×109.7(H) ×9.3(D) mm |
| Hellegkeet | 1000 cd/m² (Typ.) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 262K/16.7M |
| Frequenz | 60Hz |
| Panel Gewiicht | 185g (Typ.) |
| Signal Interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C |
| Panel Modell | AC070MR11 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | 154.4(W)×93.44(H) mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Display Modus | SWV, Normally Black, Transmissive |
| Äntwert Zäit | 15/15 (Typ.)(Tr/Td) |
| Lampe Typ | 2 strings WLED , 50K hours , Without Driver |
| Touchscreens | Without |
| Applikatioun | Industrial Outdoor High Brightness |
| A070VW04 V4 | AUO | 7.0 | 800×480 |
| AC070MD01 | Mitsubishi | 7.0 | 800×480 |
| HT07W12-200 | HYDIS | 7.0 | 480×234 |
| LA070WV1-TD04 | LG Display | 7.0 | 800×480 |
| LB070WQ5-TD01 | LG Display | 7.0 | 480×240 |
| PW070DS1T6 | E Ink | 7.0 | 480×234 |
| TCG070WVLBA-A00 | Kyocera | 7.0 | 800×480 |
| TM070DDH08 | Tianma | 7.0 | 1024×600 |
| TM070JDHP01-00 | Tianma | 7.0 | 1280×800 |
| VVX07H005A10 | Panasonic | 7.0 | 800×1280 |
