| Part Number | WG12232E-YYH-N#A |
| Mark | Winstar |
| Gréisst | 2.2 |
| Applikatioun | Industrial Instrumen |
| Opléisung | 122×32 |
| Zesummesetzung | STN-LCD , LCM |
| Hellegkeet | |
| CR | 3:1 |
| Faarwen | Monochrome |
| Géigeliicht | YG-LED |
| Interface | 8-bit |
| Mark | Winstar |
| diagonal Gréisst | 2.2 inch |
| Pixel Format | 122×32 57PPI |
| aktiv Beräich | 53.64(H)×15.64(V) mm |
| bezel Beräich | 60.0(H)×18.0(V) mm |
| luminance | - |
| Vue Richtung | 6 o'clock |
| Vue Wénkel | 30/30/20/40 (Typ.)(CR≥2) |
| Ënnerstëtzung Faarf | Monochrome |
| Gewiicht | - |
| Frame Taux | - |
| Interface Typ | 8-bit 6800/8080 parallel , 20 pins Pad |
| Stroumversuergung | 5.0V (Typ.) |
| Ëmwelt | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| Modell | WG12232E-YYH-N#A |
| Typ | STN-LCD , LCM |
| Configuratioun | Rectangle |
| kontur dim. | 80(H)×36(V) ×10.2(D) mm |
| Behandlung | - |
| Kontrast Verhältnis | 3:1 (Typ.) (TM) |
| Äntwert Zäit | 100/100 (Typ.)(Tr/Td) |
| Betribssystemer Modus | STN, Yellow/Green (Positive), Transflective |
| Liichtquell | YG-LED , 100K hours , W/O Driver |
| entworf fir | Industrial Instruments & Meters |
| Touch Panel | Without |
