| Part Number | WF57STIACDNG0 |
| Mark | Winstar |
| Gréisst | 5.7 |
| Applikatioun | Industrial |
| Opléisung | 320×240 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | Grayscale |
| Géigeliicht | WLED |
| Interface | 8/16-bit |
| Mark | Winstar |
| diagonal Gréisst | 5.7 inch |
| Pixel Format | 320×240 [QVGA] 70PPI |
| aktiv Beräich | 115.2(H)×86.4(V) mm |
| bezel Beräich | 117.9(H)×89.1(V) mm |
| luminance | 800 cd/m² (Typ.) |
| Vue Richtung | 12 o'clock |
| Vue Wénkel | - |
| Ënnerstëtzung Faarf | Grayscale |
| Gewiicht | - |
| Frame Taux | - |
| Interface Typ | 8/16-bit 6800/8080 parallel, 3/4-wire SPI , 22 pins FPC |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| Modell | WF57STIACDNG0 |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | Rectangle |
| kontur dim. | 160(H)×109(V) ×9.24(D) mm |
| Behandlung | Glare (Haze 0%) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Äntwert Zäit | - |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Liichtquell | WLED , W/O Driver |
| entworf fir | Industrial |
| Touch Panel | PCAP |
