| Part Number | WEX025664DG |
| Mark | Winstar |
| Gréisst | 5.5 |
| Applikatioun | Industrial Handheld |
| Opléisung | 256×64 |
| Zesummesetzung | PM-OLED , OLED |
| Hellegkeet | |
| CR | |
| Faarwen | Mono(Green) |
| Géigeliicht | self |
| Interface | CPU/SPI |
| Mark | Winstar |
| diagonal Gréisst | 5.5 inch |
| Pixel Format | 256×64 47PPI |
| aktiv Beräich | 135.65(H)×33.89(V) mm |
| bezel Beräich | 137.65(H)×35.89(V) mm |
| Vue Richtung | Symmetry |
| Vue Wénkel | - |
| Ënnerstëtzung Faarf | Mono(Green) |
| Gewiicht | - |
| Frame Taux | - |
| d-ic detail | TAB Built-in SSD1322UR1 |
| Interface Typ | CPU/SPI , 30 pins FPC |
| Stroumversuergung | 3.0V (Typ.) |
| Ëmwelt | Operating Temperature: -40 ~ 80 °C ; Storage Temperature: -40 ~ 80 °C |
| Modell | WEX025664DG |
| Typ | PM-OLED , OLED |
| Configuratioun | Rectangle |
| kontur dim. | 146(H)×45(V) mm |
| Behandlung | - |
| Äntwert Zäit | - |
| Betribssystemer Modus | - |
| Liichtquell | self |
| entworf fir | Industrial Handheld & PDA |
| Touch Panel | Without |
