| Part Number | WEO012832AW |
| Mark | Winstar |
| Gréisst | 2.2 |
| Applikatioun | Handheld & PDA Instr |
| Opléisung | 128×32 |
| Zesummesetzung | OLED , PM-OLED |
| Hellegkeet | |
| CR | |
| Faarwen | Mono(White) |
| Géigeliicht | self |
| Interface | 8-bit |
| Fabrikant beschwéiert | Winstar |
| Écran Gréisst | 2.2 inch |
| Pixel Zuel | 128×32 59PPI |
| aktiv Beräich (mm) | 55.018 × 13.098 (H×V) |
| Bezel Beräich (mm) | 57.02 × 15.1 (H×V) |
| Vue Wénkel | - |
| gutt Vue op | Symmetry |
| Faarfdéift | Mono(White) |
| mass | - |
| Erfrëschungsrate | - |
| Chauffer ic Lëscht | Built-in COG SSD1305Z |
| Signal Typ | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 24 pins FPC |
| Spannungsversuergung | 3.0V (Typ.) |
| Modell Numm | WEO012832AW |
| Écran Typ | OLED , PM-OLED |
| Arrangement | Rectangle |
| Kontur (mm) | 62 × 24 × 2.35 (H×V×D) |
| Behandlung | - |
| Äntwert | - |
| Aarbecht Modus | - |
| benotzt fir | Handheld & PDA Instruments & Meters |
| touchscreen | Without |
