| Part Number | WEO012832AS |
| Mark | Winstar |
| Gréisst | 2.2 |
| Applikatioun | Handheld & PDA I |
| Opléisung | 128×32 |
| Zesummesetzung | OLED , PM-OLED |
| Hellegkeet | |
| CR | |
| Faarwen | Mono(Blue) |
| Géigeliicht | self |
| Interface | 8-bit |
| Fabrikant beschwéiert | Winstar |
| Modell Numm | WEO012832AS |
| Écran Gréisst | 2.2 inch |
| Écran Typ | OLED , PM-OLED |
| Pixel Zuel | 128×32 59PPI |
| Arrangement | Rectangle |
| aktiv Beräich (mm) | 55.018 × 13.098 (H×V) |
| Kontur (mm) | 62 × 24 × 2.35 (H×V×D) |
| Bezel Beräich (mm) | 57.02 × 15.1 (H×V) |
| Behandlung | - |
| Vue Wénkel | - |
| Äntwert | - |
| gutt Vue op | Symmetry |
| Aarbecht Modus | - |
| Faarfdéift | Mono(Blue) |
| mass | - |
| benotzt fir | Handheld & PDA Instruments & Meters |
| Erfrëschungsrate | - |
| touchscreen | Without |
| Chauffer ic Lëscht | Built-in COG SSD1305Z |
| Signal Typ | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 24 pins FPC |
| Spannungsversuergung | 3.0V (Typ.) |
| CT022TN15 | Innolux | 2.2 | 176×220 |
| DLC0220KZG | Other | 2.2 | 320×320 |
| HGS128321-B-EH-LV | Other | 2.2 | 128×32 |
| LMS220GF08 | Samsung | 2.2 | 240×320 |
| LS022Q8UD04 | SHARP | 2.2 | 240×320 |
| SG12232A | Other | 2.2 | 122×32 |
| TM022GBH01 | Tianma | 2.2 | 176×220 |
| TM022HDH31 | Tianma | 2.2 | 240×320 |
| TM022HDHT1-05 | Tianma | 2.2 | 240×320 |
| TX06D15VM1EAA | KOE | 2.2 | 176×220 |
